Assingment 1
POLITEKNIK SULTAN MIZAN ZAINAL ABDIN DUNGUN TERENGGANU JABATAN KEJURUTERAAN AWAM DCC10012 – ENGINEERING DRAWING AND COMP. ADDED DRAFTING ASSIGNMENT 1 (individual) Geometry Drawing All drawing must be drawn with correct pencils to show the differences between Object lines and Construction lines 1. Without using set square and protractor, draw the angles that given below. Base of those angle are on the 100 mm line. a. 105 0 b. 75 0 2. Divide the straight line AB= 11.5cm into 7 section equally . 3. Construct the pentagon that given the diameter of circle 80 mm. 4. Use the base of pentagon AB=70 mm, complete the drawing of tha...
